PRODUCTS & SOLUTIONS

TEM ORIENTATION IMAGING
PHASE MAPPING –
ASTAR



ASTAR device uses novel TEM based orientation/phase mapping technique to characterize any material down to 1 nm scale based on collection of precession electron diffraction patterns (PED). In combination with TOPSPIN acquisition of orientation / phase / strain/ STEM maps is possible

TEM STRAIN MAPPING ANALYSIS

Novel Automated Strain Mapping Solution for TEM/STEM (Patent pending) based on nanobeam precession diffraction patterns and STEM reference image acquisition. Precision up to 0.02% (200kV FEG) with spatial resolution < 2 nm (FEG TEM). In combination with TOPSPIN acquisition of orientation /phase /strain /STEM maps is possible.

4D STEM WITH TOPSPIN PLATFORM


Scanned acquisition with
Precession electron diffraction . TOPSPIN is a digital STEM, beam Precession Electron Diffraction analytical Experimental framework offering a suite of beam precession imaging and advanced analytical experiments.

3D PRECESSION DIFFRACTION TOMOGRAPHY – MICRO ED

3D diffraction tomography in combination with DigiSTAR and precession diffraction device enable automatic reconstruction of reciprocal space, unit cell determination and crystal structure solution of any material

ANALYSIS OF AMORPHOUS MATERIALS

e-PDF software suite uses Electron Pair Distribution Function (electron diffraction based technique) that allows to analyze local order in amorphous and nanocrystalline materials from diffuse or ring ED patterns.

ELECTRIC-MAGNETIC FIELD MAPPING

4D-SPED acquisition in combination with DigiSTAR and precession diffraction can be applied to characterize local electric or magnetic fields in materials ike transistors, sensors, nanowires, batteries etc. by detecting shift of the intensity distribution of the transmited central electron beam.

ENHANCED EDS & EELS SPECTROSCOPY

Beam Precession with DigiSTAR may enhance EELS & EDX signal reducing channeling effects. EELS quantification possible via TOPSPIN model based EELS quantification.

APPLICATIONS

NEWS

NanoMEGAS Workshop 2024

Applications of Precession Enhanced Electron Diffraction

MATERIALS DEPARTMENT, UNIVERSITY OF CAMBRIDGE

JUNE 5, 2024

Precession 30 Years Anniversary

Quantum Design and NanoMEGAS are excited to announce a special workshop celebrating the 30th anniversary of beam precession development in electron diffraction for Transmission Electron Microscopy (TEM). The event will take place at Cambridge University, where the pioneers in beam precession technology has significant impact in the field.

Cambridge University and NanoMEGAS have been pivotal contributors on Precession ED applications, keeping the consistently and systematic development of novel applications and methodology improvements.

This workshop will bring together experts and researchers to explore the evolution and impact of beam precession over the past three decades. Through presentations and TEM demonstrations, we will delve into its fundamental principles, advanced applications, and future prospects.

We invite you to join us for this insightful event as we celebrate the achievements and advancements made possible by beam precession in TEM.

NanoMEGAS User Meeting 2024

Applications of Precession Enhanced Electron Diffraction

MATERIALS DEPARTMENT, UNIVERSITY OF CAMBRIDGE

JUNE 6, 2024

Precession 30 Years Anniversary

We are delighted to invite you to the NanoMEGAS User’s Meeting, celebrating the 30th anniversary of beam precession development in electron diffraction for Transmission Electron Microscopy (TEM). The event is jointly organised by Quantum Design and NanoMEGAS and will be hosted at Cambridge University, an institute with significant historical contributions to beam precession technology.

The meeting aims to showcase the latest developments and upgrades in NanoMEGAS applications, including faster data collection, utilisation of 4D-SPED for advanced applications, integration with various detectors, synergy with in-situ studies, etc.

The invitation is exclusively for experienced NanoMEGAS system users.

In the second part of the meeting, selected scientific works will be presented, highlighting recent advancements and results. We are excited to invite you to present your latest scientific results, using NanoMEGAS applications.

Early registration is highly recommended as the schedule and presentation slots will be limited. Your timely response will help us organise the agenda effectively and ensure your participation in this insightful event.

Further details regarding the agenda will be provided to you soon.

Your contribution will add significant value to the discussions and enrich the collective knowledge sharing during this milestone celebration.

NanoMEGAS is partner of the European Network for Transmission Electron Microscopy with expertize in electron difffraction/crystallography techniques and TEM orientation imaging

Read more at : www.esteem3.eu

ESTEEM3 – Enabling Science and Technology through European Electron Microscopy – is an EU funded project for electron microscopy, which aims at providing access to the leading European state-of-the-art electron microscopy research infrastructure. Facilitating and extending transnational access services of the most powerful atomic scale characterization techniques in advanced electron microscopy research to a wide range of academic and industrial research communities for the analysis and engineering of novel materials in physical, chemical and biological sciences.

ESTEEM3’s objective is to deliver access to users coming from a wider range of disciplines. Transnational Access (TA) to ESTEEM3 centers is obtained through a transparent, simple peer review process based on merit and scientific priorities. Optimum service to users is supported by Networking Activities (NA) and Joint Research Activities (JRA), which address key issues such as specimen preparation, data interpretation, treatment and automation through theory and simulation, and standardization of protocols and methodologies.

EVENTS

PICO2024

21 to 25 April 2024
Vaals, Netherlands

Advanced Analytical Methods
for Formulation Development

4 to 5 June 2024
Darmstadt, Germany



Microscopy & Microanalysis

28 July to 1 August 2024
Cleveland, OH, USA

emc2024

25 to 30 August 2024
Copenhagen, Denmark
